DC motor from the DCK31 series with worm gearbox and a rated voltage of 24V. Maximum torque 27.6Nm, idle speed 120 rpm.
Additional information
| Series | DCK31 |
|---|---|
| Voltage | 24v |
| Max. Torque | 27.6Nm |
| Idle | 120 rpm |
| Nominal power | 137W |
| Rated current | 5.7A |
| Idle current | 2A |
| Max. current | 27.9A |
| Hall Sensors | |
| Reduction | 53:2 |
| Gear material | P |
| Thermoswitches | N |
| Interference supression | Y |
| Gearbox | Lh |
| Characteristic | DCK31 K16 |
| Shaft | DCK31 W7 |
| Electr. Connection | DCK31 A1 |
